      Legend for Geotechnical Data
      Grain Size Scale for Sediments
      Proportional Definition of Descriptive Terms
      Descriptive Term
      Range of Proportions
      Sandy, gravelly, etc.
      35 % to 50 %
      Some
      20 % to 35 %
      Little
      10 % to 20 %
      Trace
      1 % to 10 %
      Consistency of Cohesive Soils
      Description
      Consistency
      Index
      Approximate
      Undrained Shear
      Strength (kPa)
      Field Identification
      Hard
      Over 300
      Indented with difficulty by thumbnail, brittle.
      Very Stiff
      >1
      150-300
      Readily indented by thumbnail, still very tough.
      Stiff
      0.75-1
      75-150
      Readily indented by thumb but penetrated only with difficulty. Cannot
      be moulded in the fingers.
      Firm
      0.5-0.75
      40-75
      Can be penetrated several centimeters by thumb with moderate effort
      and moulded in fingers by strong pressure.
      Soft
      < 0.5
      20-40
      Easily penetrated several centimeters by thumb, easily moulded.
      Very Soft
      Less than 20
      Easily penetrated several centimeters by fist, exudes between fingers
      when squeezed in fist.
      Source:
      Engineering Properties of Soils and Rocks, Fourth Edition by Fred G. Bell
      alt
      alt
      alt
      alt
      alt
      alt
      alt
      alt
      alt
      alt
      alt
      alt
      alt
      USCS Classifications
      Refers to the Army Corps of Engineers Unified Soils Classification System. Class types
      are defined primarily by grain size, sorting and percent of material passing the #200 sieve.
      Classification of materials on the core logs based on visual field examinations are identified on
      the core logs under the Classification of Materials Description. Classifications based on
      laboratory sieve analyses are identified on the core logs in the Legend and under Remarks.
      Note:
      Information is after ACOE Atlantic Division Manual # 1110-1-1 titled
      Engineering and Design
      Geotechnical Manual for Surface and Subsurface Investigations
      alt
      LEAN CLAY, very soft, trace sand, fine grained,
      quartz, trace shell hash, sand distributed in laminae,
      dark gray (5Y-4/1), (CL).
      SAND, fine grained, quartz, trace shell hash, trace silt,
      very dark gray (5Y-3/1), (SP).
      LEAN CLAY, very soft, trace shell hash, 1.5" shell
      hash pockets @ 3.2' and 3.5', dark gray (N-4/0), (CL).
      SAND, fine grained, quartz, trace clay, trace silt, clay
      distributed in pockets up to 1.0", clay decreases
      with depth in layer, color is mottled dark gray
      (N-4/0) and dark greenish gray (10Y-4/1), (SM).
      SAND, fine grained, quartz, trace clay, trace silt, silt
      distributed in pockets up to 0.5", 1.5" clay pocket @
      7.1', 0.5" clay pocket @ 7.5', light brownish gray
      (10YR-6/2), (SP).
      SAND, fine grained, quartz, trace clay, trace shell
      hash, trace silt, oxidation throughout layer, (1.5" x
      3.0") clay pocket @ 9.1', brown (7.5YR-4/4), (SP-SM).
      FAT CLAY, hard, oxidation throughout layer, color
      is mottled yellowish brown (10YR-5/6) and gray
      (5Y-5/1), (CH).
      FAT CLAY, hard, color is mottled greenish gray
      (10Y-5/1), very dark gray (5YR-3/1) and brown
      (7.5YR-4/4), (CH).
      FAT CLAY, hard, Bit sample from 16.2' to 16.7',
      brown (7.5YR-4/4), (CH).
      No recovery.
      End of Boring
