09CCT02_14 Core Location
251
09CCT02_14 Seismic
252
09CCT02_14 Seismic
253
09CCT02_14 Percent Grain Size Distribution Graph
09CCT02_14 Percent Gravel, Sand, Silt, and Clay
0
100
200
300
400
500
600
0
10
20 30 40 50 60 70 80
90
100
Percent (%)
Depth (cm)
Gravel
Sand
Silt
Clay
09CCT02_14 Mean Grain Size Distribution Graph
09CCT02_14 Mean Grain Size
0
100
200
300
400
500
600
0
50
100
150
200
250
300
350
400
450
Grain Size (μm)
Depth (cm)
Mean Grain Size
254
09CCT02_14 Strength Graph
09CCT02_14 Strength
0
100
200
300
400
500
600
012
34
5
Strength (kg/cm²)
Depth (cm)
Strength
09CCT02_14 Water Content Graph
09CCT02_14 Water Content
0
100
200
300
400
500
600
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
Water Content (g)
Depth (cm)
Water Content
255
09CCT02_14 Grain Size Sand Percent Table
09CCT02_14 Grain Size Sand Percent
Depth (cm)
63-
257
μm
(%)
257-
451
μm
(%)
451-
645
μm
(%)
645-
839
μm
(%)
839-
1033
μm
(%)
1033-
1227
μm
(%)
1227-
1421
μm
(%)
1421-
1615
μm
(%)
1615-
1809
μm
(%)
1809-
2000
μm
(%) Total (%)
0-3
87.16 5.12 1.90 1.57
1.43 1.14
0.79
0.50 0.25 0.14
100
10-15 27.10 7.93 10.03 13.34
13.13
10.78
7.83
5.35 2.83 1.69
100
25-28 70.90 18.71 3.40 1.80
1.65
1.36
0.98
0.66 0.34 0.20
100
40-45 31.72 7.21 10.79 13.09
12.22
9.70
6.86
4.60 2.39 1.43
100
110-115 18.97 8.26 12.55 15.27
14.40 11.60
8.40
5.63 3.20 1.71
100
184-189
59.40 2.56 7.23 8.56
7.54 5.77
4.02
2.68 1.40 0.83
100
214-219
71.28 3.31 4.68 5.45
4.89 3.89
2.83
1.97 1.07 0.64
100
239-244 70.03 10.42 7.00 4.86
3.15 1.99
1.22
0.75 0.37 0.21
100
274-279
63.64 8.24 8.64 7.23
5.14 3.28
1.97
1.04 0.58 0.25
100
315-320
68.51 8.29 6.27 5.12
4.00 2.99
2.14
1.40 0.85 0.43
100
335-340 52.04 19.89 12.68 7.30
3.96 2.09
1.09
0.57 0.25 0.13
100
345-350 48.12 21.35 13.83 8.07
4.38 2.27
1.16
0.48 0.24 0.10
100
370-375 55.13 18.18 11.69 7.06
3.97 2.10
1.07
0.47 0.24 0.08
100
389-394 46.26 19.53 13.36 8.67
5.33 3.17
1.83
1.06 0.50 0.28
100
400-405 50.99 21.54 13.44 7.39
3.74 1.76
0.80
0.24 0.09 0.02
100
420-425
44.43 10.18 11.48 10.83
8.65 6.13
3.95
2.45 1.20 0.69
100
466-471
39.28 11.30 13.28 11.89
9.03 6.30
4.13
2.65 1.35 0.79
100
546-551 50.03 20.13 12.72 7.65
4.39 2.46
1.35
0.75 0.34 0.19
100
561-566 47.85 19.73 12.88 8.16
4.96 2.95
1.72
0.99 0.51 0.25
100
576-581 46.96 14.84 13.06 9.99
6.63 4.03
2.30
1.29 0.58 0.32
100
